8-Port DP KVM-Switch 4K60Hz USB 2.0 Audio with Hotkey and RS232 Control, Uniclass RP-1080A

8-Port DP KVM-Switch 4K60Hz USB 2.0 Audio with Hotkey and RS232 Control, Uniclass RP-1080A

The RP-1080A/RP-1160A are 8-port/16-port Rack-mountable DisplayPort KVM Switches with the DisplayPort 4K at 60Hz video interface, audio, USB 2.0 hub, Hotkey and RS-232 control. These unique KVM Switches simplified the management of multiple multimedia computers with the DP 1.2 video interface. Users can control 8/16 computers using only one keyboard, one mouse, one monitor and a set of speakers/headphones.
The RP-1080A/RP-1160A support multimedia keyboard and mouse. Multi-platform support such as PC and Mac. is also available. It features the specification of HDMI 2.0, not only a popular display interface of consumer electronics but also the increased bandwidth, compared with the previous versions of DP 1.1. For even more convenience, there are USB 2.0 hub for high-speed USB device sharing. We also offer five hotkey preceding sequence keys for users' free configuration on the hotkey preceding sequence key other than two <ScrLk>.


• 8-port Rack-mountable DisplayPort 1.2 KVM Switch w/ Audio, USB 2.0 Hub, Hotkey and RS-232 control.
• Source to End DP video interface.
• Unique DP/Audio/USB-Hub interface for multimedia needs.
• Includes Rack Mount Kit for easy installation into server rack cabinet.
• 2 extra USB device ports for high-speed USB device sharing.
• Independent peripheral switching configurable by hotkeys.
• Simultaneous/independent switching of PC/USB hub/audio port selection.
• RS-232 Serial Control.
• Supports digital video resolution up to 3840 x 2160 4K@60Hz.
• Supports Windows 7/10/11, Linux and Mac OS.
• Multi-platform support PC and Macintosh.
• Status LED display for easy port status monitoring.
• Buzzer sound for port switching confirmation.
• Metal enclosure for best shielding and protection.
• Firmware upgradable via USB port.
• DP 1.2/1.1/1.0 Specification compliant.
• DP 1.2 technology supports High Quality Digital Video.



Connection Diagram:



scope of delivery:

8-Port DP KVM-Switch x 1
Power adapter x 1
19" Rackmount Brackets x 1
Manual (QIC) x 1
